LED High Bay Light VIDEX HB01 100W 5000K 18000Lm Black
Features
Article
VL-HB01-1005B
Category
High Bay light
Power
100 W
Luminous flux
18000 Lm
Correlated color temperature
5000K (daylight)
Color rendering index (CRI)
Ra > 70
Voltage
AC 110-277 V
Frequency
50/60 Hz
Luminous Efficacy
180 Lm/W
Energy class
А++
Energy class (EU)
B
Beam angle
90°
Warm-up time to 100% of full luminous flux
Миттєвий старт (<1 сек)
Dimmable
Не підтримує
Lifetime (L70B50)
50000h
ON/OFF cycles
25000
Protection class, IP
65
Displacement factor (cos φ1)
0.95
Maximum amperage
500mA
The lumen maintenance factor
≥96%
Colour consistency in MacAdam ellipses (SDCM)
<6
Peak luminous intensity
9781 cd
Operating temperature range
-30°C ~ + 50°С
Mounting type
Suspended
Materials
Aluminum
Sizes
265mm x 148mm
Colour
Black
Weight
1.55kg
Warranty period
3 years
Quantity in pack
1шт
Quantity in carton
4 шт
Barcode
2176
