Ceiling plan
LED Surface Downlight square VIDEX 24W 5000K Black
Features
Article
VL-DLSS-245B
Category
Downlight
Power
24 W
Luminous flux
1920 Lm
Correlated color temperature
5000K (daylight)
Color rendering index (CRI)
Ra > 80
Form factor
Square
Voltage
AC 185-265 V
Frequency
50/60 Hz
Luminous Efficacy
80 Lm/W
Energy class
А+
Energy class (EU)
E
Beam angle
170°
Warm-up time to 100% of full luminous flux
Миттєвий старт (<1 сек)
Dimmable
Не підтримує
Lifetime (L70B50)
30000h
ON/OFF cycles
20000
Protection class, IP
20
Displacement factor (cos φ1)
0.7
Maximum amperage
174mA
The lumen maintenance factor
≥94.8%
Colour consistency in MacAdam ellipses (SDCM)
<6
Peak luminous intensity
335 cd
Operating temperature range
-20°C ~ + 40°С
Mounting type
Накладний
Materials
Iron, glass, polycarbonate
Sizes
264mm x 264mm x 29mm
Colour
Black
Weight
1kg
Warranty period
2 years
Quantity in pack
1шт
Quantity in carton
20pcs
Barcode
565
UAH
Calculation results:
Parameter
Value
Number of lamps (pcs)
-
Average illuminance (lux)
-
Min. illumination (lux)
-
Max. illumination (lux)
-
Uniformity (min / av)
-
Extra equal (min / max)
-
Use coef.
-
