Ceiling plan
LED round frameless lamp VIDEX 24W 4100K
Features
Article
VL-DLFR-244
Category
Downlight
Power
24 W
Luminous flux
2400 Lm
Correlated color temperature
4100К (біле світло)
Color rendering index (CRI)
Ra > 80
Features
Frameless
Form factor
Round
Voltage
AC 185-265 V
Frequency
50/60 Hz
Luminous Efficacy
100 Lm/W
Energy class
А+
Energy class (EU)
E
Beam angle
160°
Cut-out diameter
65-142 mm
Warm-up time to 100% of full luminous flux
Миттєвий старт (<1 сек)
Dimmable
Не підтримує
Lifetime (L70B50)
35000h
ON/OFF cycles
20000
Protection class, IP
20 / 54
Displacement factor (cos φ1)
0.7
Maximum amperage
150mA
The lumen maintenance factor
≥96%
Colour consistency in MacAdam ellipses (SDCM)
<6
Peak luminous intensity
462 cd
Operating temperature range
-20°C ~ + 40°С
Mounting type
Вбудований
Materials
Iron, polycarbonate, aluminum
Sizes
172mm x 20mm
Colour
White
Weight
280g
Warranty period
2 years
Quantity in pack
1шт
Quantity in carton
20pcs
Barcode
451
UAH
Calculation results:
Parameter
Value
Number of lamps (pcs)
-
Average illuminance (lux)
-
Min. illumination (lux)
-
Max. illumination (lux)
-
Uniformity (min / av)
-
Extra equal (min / max)
-
Use coef.
-
